WF762F1A0902 Wiser Add-On 6-Zone UFH Hydronic Heating & Cooling DIN Rail

Drayton Wiser Underfloor Heating Controller (WF762F1A0902) — Smart control for hydronic (water-based) underfloor heating  |  Up to 6 UFH zones per controller  |  14 thermal actuator outputs  |  Heating & cooling (reversible heat pump ready)  |  Wiser app control  |  DIN rail mount with remote antenna  |  Works with all Wiser kits

6UFH Zones per controller
14Thermal actuator outputs
3Controllers per system
16Total zones (full system)
30mWireless radio range
230VPower supply

Smart Hydronic Underfloor Heating — Integrated into Wiser

The Drayton Wiser Underfloor Heating Controller (WF762F1A0902) brings water-based (hydronic) underfloor heating into the Wiser smart home ecosystem, allowing it to be controlled and scheduled alongside radiators from a single app. It connects wirelessly to the Wiser HubR via ZigBee, enabling remote control, smart scheduling and voice assistant integration without any additional wiring between the manifold and the controller.

Each controller manages up to 6 independent UFH zones using up to 14 thermal actuator outputs, and includes dedicated boiler and pump contacts to provide flow on demand. Where heating and cooling is needed — for example with a reversible heat pump — the controller supports both modes automatically. Up to 3 controllers can be used in a single system, providing up to 16 zones of total heating and cooling control across the whole property.

✅ Can be commissioned and tested without a Wiser HubR or Wi-Fi connection — useful for installer pre-testing before the hub is installed.

Key Features

🌊 Multi-Zone Hydronic UFH Controls up to 6 zones of water-based underfloor heating per controller. Each zone requires one Wiser Room Thermostat (sold separately).
❄️ Heating & Cooling Supports both heating and cooling modes. Compatible with reversible heat pump systems for year-round climate control.
⏱️ 30-Second Relay Delay Staggered 30-second delay between relay switching prevents simultaneous actuation of all zones — protecting the pump and boiler from sudden load surges.
🔧 DIN Rail Mount Installs on a standard DIN rail inside a consumer unit or manifold cabinet. Remote antenna is included for reliable ZigBee signal from within metal enclosures.
📡 Offline Commissioning Can be fully set up and tested without Wi-Fi or the Wiser HubR — ideal for pre-commissioning before the hub is connected.
🏠 Mixed System Ready Pairs seamlessly with Wiser Radiator Thermostats to create a mixed wet radiator / UFH system, all controlled from one app and one hub.
📱 Full App & Voice Control Remote control and scheduling via the Wiser Home app. Compatible with Amazon Alexa and Google Assistant.
🔌 Boiler & Pump Contacts Dedicated volt-free contacts for boiler and circulation pump — ensures the system only calls for heat when a UFH zone is open.

What's Included in the Box

✅ 1× Wiser UFH Controller
✅ 1× DIN Rail
✅ 1× Remote Antenna
✅ Installation Guide
⚠️ Sold separately — required for operation The Wiser UFH Controller requires a Wiser HubR (any generation) and one Wiser Room Thermostat per zone. Thermal actuators (TS Ultra or compatible) must also be fitted to the UFH manifold. None of these are included.

Technical Specifications

Parameter Specification
Part Number WF762F1A0902
Power Supply 230V a.c., 50Hz — fixed wiring
Maximum Zone Inputs (per controller) 6 room thermostat inputs
Maximum Actuator Outputs (per controller) 14 thermal actuator outputs
Maximum Controllers per System 3 (up to 16 total zones)
Relay Switching Delay 30 seconds between relay activations
Boiler & Pump Contacts Yes — volt-free
Heating / Cooling Both — reversible heat pump compatible
Wireless Protocol ZigBee 2.4GHz
Wireless Range 30m open air (remote antenna included for metal enclosures)
Mounting DIN rail (included) — bottom cable entry
Enclosure Material ABS plastic
Current Rating 3.15A
Voice Assistants Amazon Alexa, Google Assistant, IFTTT
App Wiser Home app — iOS & Android (free)
Offline Commissioning Yes — can be tested without HubR or Wi-Fi
Compatible Wiser Kits All Wiser kits (HubR required for app control)
Guarantee 1.5 years

System Design Guidance

Each UFH zone requires:

  • One Wiser Room Thermostat (wireless, battery-powered) positioned in the zone to measure room temperature
  • One or more thermal actuators (e.g. Wiser TS Ultra) fitted to the UFH manifold loops serving that zone

The controller then opens and closes the actuators based on the thermostat's demand signal, and fires the boiler/pump contacts when any zone calls for heat. For cooling systems (reversible heat pump), the controller switches to cooling mode automatically when the connected heat pump operates in reverse.

Frequently Asked Questions

Can I use this alongside radiators on the same Wiser system? Yes. The UFH controller integrates fully with the rest of the Wiser ecosystem. You can combine it with Wiser Radiator Thermostats, a Wiser HubR and Room Thermostats to create a complete mixed wet heating system — all managed from the same Wiser Home app.
Do I need a separate Wiser HubR for the UFH controller? No. The UFH controller connects to your existing Wiser HubR via ZigBee. One HubR serves the entire Wiser system — radiator thermostats, UFH controller, smart plugs and all other Wiser devices. Up to 3 UFH controllers can share a single hub.
What actuators are compatible? The controller is designed to work with 230V normally-closed thermal actuators. The Wiser TS Ultra thermal actuator is the recommended accessory. Check the installation guide for full actuator compatibility details.
Can I use the controller for cooling as well as heating? Yes. When connected to a reversible heat pump system, the controller supports both heating and cooling operation. Individual zones can be set to heating or cooling mode from the Wiser Home app.
Why is there a 30-second delay between relays switching? The staggered delay prevents all zone actuators from opening simultaneously, which would cause a sudden large flow demand that could stress the pump or boiler. The sequential startup protects the system and extends component life.
