Victron SmartSolar MPPT 150/60-TR – 60A Solar Charge Controller
The Victron SmartSolar MPPT 150/60-TR is a high‑performance 60A solar charge controller designed to maximise energy harvest from your PV array while protecting and extending the life of your battery bank. Its ultra‑fast MPPT tracking, built‑in Bluetooth and advanced battery management make it an ideal choice for both residential and professional solar installations.
Key Features
- Ultra‑fast MPPT algorithm continuously tracks the optimum power point to extract more energy from your solar panels, especially under changing or partly cloudy conditions.
- Advanced Maximum Power Point Detection intelligently handles partial shading, helping to avoid local maxima and improving real‑world yield compared with basic controllers.
- High conversion efficiency (over 98%) reduces energy loss as heat, improving overall system performance and helping to keep running costs low.
- Automatic 12/24/48V battery voltage recognition (36V selectable via software) for flexible integration with new or existing systems.
- BatteryLife intelligent management actively prevents chronic under‑charging by managing connected loads, supporting longer battery service life.
- Built‑in Bluetooth Smart for easy setup, monitoring and firmware updates via the VictronConnect app – no external dongle required.
- Flexible multi‑stage charge algorithm with user‑programmable settings to suit lead‑acid and lithium battery technologies.
- Robust electronic protection including over‑temperature protection with automatic power derating, PV reverse polarity, output short‑circuit and over‑current safeguards.
- Optional plug‑in SmartSolar display and compatible accessories allow on‑device system monitoring where preferred.
Why Buy
- Designed by a leading European power electronics manufacturer, this controller offers proven reliability for off‑grid, hybrid and backup power systems.
- MPPT technology can deliver up to around 30% more energy than traditional PWM controllers in variable conditions, helping you get more usable power from the same array size.
- Intelligent charging, temperature compensation and protective features work together to reduce battery stress and support a longer battery lifespan.
- Integrated Bluetooth and app control simplify commissioning, performance monitoring and fault diagnosis, reducing install time and site visits for professionals.
- Wide PV input range (up to 150V open‑circuit) means multiple panels can be wired in series, allowing longer string runs and smaller DC cable sizes.
Suitable For
- Homeowners upgrading from PWM to MPPT controllers to increase yield from existing rooftop or ground‑mount solar arrays.
- New residential and light commercial off‑grid or hybrid systems using 12V, 24V, 36V or 48V battery banks.
- Professional installers working on cabins, workshops, agricultural buildings and energy storage systems that require dependable MPPT performance.
- Marine, caravan, motorhome and mobile applications where rugged design, compact form factor and remote monitoring are important.
- Systems with partial shading or mixed orientation arrays, where advanced MPPT tracking delivers better real‑world results.
Technical Specifications
| Model | Victron SmartSolar MPPT 150/60-TR |
|---|---|
| MPN | SCC115060211 |
| EAN | 8719076051381 |
| Battery system voltage | 12 / 24 / 48 V auto‑select; 36 V selectable via software tool |
| Rated charge current | 60 A |
| Maximum PV open‑circuit voltage | 150 V DC |
| Maximum PV short‑circuit current | 50 A (array Isc) |
| Recommended nominal PV power | 12 V: 860 W; 24 V: 1720 W; 48 V: 3440 W (approximate guidance) |
| Charge algorithm | Multi‑stage adaptive; eight pre‑programmed algorithms or user‑defined via software |
| Battery types | Lead‑acid (flooded, AGM, gel) and lithium (LiFePO₄) with suitable settings |
| Communication | Integrated Bluetooth Smart; VE.Direct port |
| Protection & safety | PV reverse polarity, output short‑circuit, over‑temperature with automatic power derating, electronic protections |
| Operating temperature | Approx. −30 °C to +60 °C (full output up to around 40 °C) |
| Enclosure protection | Electronics IP43, connection area IP22 (typical for SmartSolar range) |
| Dimensions (H × W × D) | Approx. 250 × 185 × 95 mm |
| Weight | Approx. 3 kg |
| Connections | TR (screw terminal) PV and battery connections |
| Display options | Optional plug‑in SmartSolar LCD display (sold separately) |
| Monitoring & control | VictronConnect app via Bluetooth; integration possible with wider system monitoring platforms |
