Sigenergy SigenStor Battery Module with LED | BAT LED | 5–9kWh LiFePO4 Stackable Storage All Variants
Sigenergy SigenStor Battery Module with LED | BAT LED | 5–9kWh LiFePO4 Stackable Storage All Variants
The SigenStor Battery Module is a floor-standing, stackable LiFePO4 battery module with integrated LED status indicator, designed exclusively for use with the SigenStor Energy Controller. Between one and six modules can be installed per Energy Controller stack (five if the EV DC Charging Module is also fitted), giving usable storage from approximately 4.8 kWh up to around 54 kWh in a single stack. Quick-connect cabling enables fast installation without specialist tooling. The AI-enabled Battery Management System optimises cycle life based on usage patterns and system conditions, and battery state is visible at a glance on the physical LED strip and remotely via the mySigen App. Four capacity variants are available: 5.0 kWh, 6.0 kWh, 8.0 kWh, and the 10.0 (9.04 kWh actual) — the highest-energy module per unit.
- LiFePO4 chemistry — safer, longer cycle life, better high-temperature stability than NMC
- Integrated LED status strip — charge state visible without app at a glance
- Quick-connect DC cabling — tool-free connection, fast installation
- Stack 1–6 modules per Energy Controller (1–5 with EVDC module fitted)
- Mixed module sizes supported in the same stack — flexible capacity increments
- AI Battery Management System — learns usage patterns, extends cycle life
- mySigen App — real-time SoC, charge/discharge history, health monitoring
- Compatible with both SP (single phase) and TP (three phase) Energy Controllers
- 10-year product warranty
| Nominal Capacity | SKU | Manufacturer MPN | Approx. Usable | Notes |
|---|---|---|---|---|
| 5.0 kWh | SIG-STOR-BAT-5.0 | SigenStor BAT 5.0 | ~4.8 kWh | Entry module · cost-effective starting point for retrofit |
| 6.0 kWh | SIG-STOR-BAT-6.0 | SigenStor BAT 6.0 | ~5.8 kWh | Mid-range module |
| 8.0 kWh | SIG-STOR-BAT-8.0 | SigenStor BAT 8.0 | ~7.7 kWh | Most widely specified module · balanced cost / capacity |
| 9.04 kWh Named 10.0 | SIG-STOR-BAT-9.04 | SigenStor BAT 10.0 | ~8.76 kWh | Highest-energy module · Mfr MPN uses "10.0" label — see capacity note above |
| Battery Chemistry | LiFePO4 (Lithium Iron Phosphate) |
| Depth of Discharge | ~96.7% (BAT 10.0) · ~96% (BAT 8.0) |
| Max Charge/Discharge Power | 4,600 W per module |
| Voltage Range (Single Phase) | 300–600V DC |
| Voltage Range (Three Phase) | 600–900V DC |
| Modules per Stack | 1–6 (1–5 with EVDC module); mixed sizes supported |
| Dimensions (BAT 10.0) | 767 × 270 × 265 mm |
| Weight (BAT 10.0) | 78 kg |
| Operating Temperature | −10°C to +50°C |
| Protection Rating | IP55 (indoor installation recommended) |
| Warranty | 10 years |
