SolaX X1 G4 (Single Phase) Hybrid Inverter Range with Wi-Fi
The SolaX X1 G4 Hybrid Inverter series is a premium range of single-phase hybrid inverters, perfect for residential solar and battery storage systems. These inverters offer seamless integration with solar PV and high-voltage battery storage, enabling efficient energy management, backup capability, and future-ready smart home features.
Key Features
- Seamless integration with solar PV and battery storage
- Supports up to 200% PV oversizing
- Smart load management (EV charger and heat pump integration)
- Rapid shutdown and AFCI (optional)
- Type II SPD (AC & DC) for enhanced protection
- Remote monitoring and management via SolaX Cloud
- 10-second data refresh for real-time performance tracking
- Easy setup with WiFi and app-based configuration
- I-V curve diagnosis and global MPP scan
- Supports parallel operation (up to 5 inverters, no external EMS required)
- Fanless, silent operation for quiet installation
Model Range & Key Specifications
- Available Models: 3.0kW, 3.7kW, 5.0kW, 6.0kW, 7.5kW, 8.0kW, 10.0kW
- MPP Voltage Range: 70–550V (Hybrid G4), 40–560V (VAST models)
- Max DC Input Power: Up to 20,000W (model dependent)
- Number of MPPTs: 2 (Hybrid G4), 4 (VAST models)
- Max. Input Current per MPPT: 16A
- Max. Efficiency: 98%
- European Efficiency: 97%
- AC Output Power: 3.0kW to 10.0kW (model dependent)
- Battery Compatibility: SolaX Triple Power high-voltage batteries
- Built-in WiFi: Yes (WiFi dongle included as standard)
- Export Limitation: Built-in export control
- IP Rating: IP66 (indoor/outdoor use)
- Operating Temperature Range: -25°C to +60°C
- Warranty: 10–12 years
Applications
- Residential solar-plus-battery installations
- Backup power and self-consumption optimisation
- Smart home energy management
