Strom 9kW Single Phase Heat Only Electric Boiler
The Strom 9kW Single Phase Heat Only Electric Boiler delivers reliable central heating without the bulk — a compact, wall-mounted unit purpose-built for properties where space is at a premium or where built-in pumps and expansion vessels simply aren't needed. With zero carbon monoxide emissions, near-silent operation and a patented serpentine heat exchanger, this is the clean, quiet alternative to gas that fits almost anywhere in your home.
This boiler must be installed by a qualified electrician who is a member of a competent persons scheme. A Part P electrical certificate and notification under Building Regulations are legally required. The heating circuits must also be designed and commissioned by a competent plumber or heating engineer.
Unlike a system boiler, the Heat Only variant has no built-in pump, expansion vessel or pressure relief valve. You will need to supply and fit: circulating pump, expansion vessel & kit, pressure gauge, automatic bypass valve, isolation valves, and external heating controls (programmer + room thermostat or programmable thermostat).
Strom's unique heat exchanger distributes heat evenly across the entire element surface, eliminating hot spots that cause limescale and corrosion. The result is a longer-lasting element and consistently efficient heat transfer.
With no combustion, no flue and no carbon monoxide, this boiler can be installed in virtually any room. Minimal moving parts mean whisper-quiet performance day and night.
At just 520 × 235 × 120 mm, the unit is considerably smaller than a conventional boiler. Wall-mounted via an integrated bracket with supplied expanding bolts, it fits neatly in cupboards, utility rooms or airing cupboards.
Every kilowatt drawn from the supply converts directly to heat — no flue losses, no standby pilot flame. Pair with a green electricity tariff or your own solar panels to reduce running costs further.
An onboard frost-protection mode activates automatically to safeguard the boiler and pipework in unheated spaces. For external outbuildings, Strom recommends adding an external frost stat wired inline.
The fully modular component layout means individual parts can be replaced without swapping the whole unit, keeping long-term maintenance costs low. The heating element is a single replaceable assembly — straightforward for any qualified engineer.
A dedicated switch-live thermostat terminal on the PCB accepts any standard room thermostat or programmable thermostat, giving you full flexibility over how your heating schedule is managed.
Compatible with solar PV divert systems (e.g. via an immersion controller), making this boiler an excellent companion to on-site generation. It's also the go-to choice for properties not connected to the gas network.
| Heat Output | 9 kW |
| Phase | Single Phase (230 VAC) |
| Current Draw @ 230 VAC | 41 A |
| Minimum MCB / RCB Breaker | 45 A |
| Minimum Cable Size | 6 mm² |
| Heating Temperature Range | 20 °C – 80 °C |
| Heating Pressure Range | 0.5 – 1.5 Bar |
| Heating Flow & Return Connection | ¾" Male BSP (flexi hoses or push-fit irons recommended) |
| PRV Connection Size | 15 mm Compression |
| Dimensions (H × W × D) | 520 × 235 × 120 mm |
| ERP Rating (Heating) | D |
| Warranty | 2 years when registered within 45 days of purchase (1 year if unregistered) |
| Compliance | BS EN 12828, BS EN 12831, BS EN 14336, BS7671 (IEE 19th Ed), BS EN 7593, Part L 2022 |
| What's in the Box | Heat Only Boiler, integrated wall mounting bracket, 3× expanding wall bolts, wall mounting guide, installation manual |
