Grundfos Home Booster Unit MD300200 – 3 Bar Water Pressure Booster Set for Domestic Use
Grundfos Home Booster Unit MD300200 – 3 Bar Water Pressure Booster Set for Domestic Use
The Grundfos Home Booster Unit MD300200 is a high-quality single pump water pressure booster set, designed to enhance mains water supply pressure for domestic properties. Equipped with an integrated 200-litre stainless steel storage tank (180 litres usable volume) and a PM2 Pressure Manager controller, this unit reliably delivers up to 3 bar pressure to meet the demands of households with one to two bathrooms and standard fittings.
Why Buy the Grundfos Home Booster MD300200?
- Integrated Storage Tank: Features a 200-litre tank with 180 litres usable capacity for maintaining steady water supply and reducing pump cycling.
- Efficient Pressure Management: The PM2 Pressure Manager controls pump operation with on/off functionality, fault alerts, and protection against dry run and blockages.
- Reliable Performance: Delivers nominal 3 bar pressure (up to 3.6 bar max) with a maximum flow rate of 72 litres per minute (1.2 l/sec), suitable for typical domestic water demand.
- High-Quality Components: Stainless steel pump and WRAS-approved components ensure durability and compliance with water regulations.
- Compact and Ready to Install: Packaged as a ready-to-install unit with simple mains water, discharge, overflow, and electrical connections.
- Energy and Space Efficient: Compact floor-standing design with efficient pump motor sized at 588W, consuming 2.8 amps at full load.
- Modular Expandability: Multiple units can be combined for increased capacity or standby pumping in larger installations.
- Compliance and Safety: Includes a Type AB air gap in the tank, meeting Water Byelaws requirements and ensuring safe water supply.
- Manufacturer Warranty: 2-year guarantee for peace of mind.
Suitable For
- Domestic properties with one to two bathrooms requiring boosted mains water pressure.
- Homes with standard fittings including en-suites and cloakrooms.
- Households seeking a compact, efficient, and reliable pressure boosting solution.
- Situations requiring compliance with UK Water Regulations and WRAS approval.
- Properties with slow tank refill rates benefiting from optional slave tank expansion.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | MD300200 |
| Maximum Pressure | 3.6 Bar (Nominal 3 Bar) |
| Maximum Flow Rate | 72 litres per minute (1.2 l/s) |
| Usable Tank Capacity | 180 litres |
| Tank Material | Stainless Steel with Type AB Air Gap |
| Pump Motor Power | 588 W |
| Full Load Current | 2.8 Amps |
| Dimensions (H x W x D) | 1000 mm x 600 mm x 600 mm |
| Weight | 65 kg |
| Voltage | 240 V, 1 phase, 50 Hz |
| Sound Level | < 65 dB(A) |
| Controller | PM2 Pressure Manager with on/off and fault functions |
| Approvals | WRAS Approved |
| Warranty | 2 Years |
MPN: MD300200
EAN: 5710625340843
$2,959.83
