EcoFlow Power Ocean Wall-Mounted Bracket
The EcoFlow Power Ocean Wall-Mounted Bracket is a heavy-duty mounting solution designed specifically for securing EcoFlow Power Ocean LFP battery modules and hybrid inverters to walls in residential solar energy storage installations.
Product Description
This precision-engineered bracket provides secure wall mounting for Power Ocean 5kWh battery modules (single or stacked configurations) and compatible hybrid inverters. Constructed from high-strength aluminium alloy with anti-corrosion coating, it supports both indoor and outdoor installations while maintaining IP65 system integrity.
Key Features
- Universal compatibility: Fits all Power Ocean 5kWh LFP batteries and 3.6kW/6kW single-phase hybrid inverters.
- Heavy-duty construction: Supports 60+kg battery weight with 4-point anti-vibration mounting.
- Easy installation: Pre-drilled holes match standard wall studs; includes all necessary fixings and template.
- Weatherproof design: Marine-grade aluminium with UV-resistant powder coating for outdoor durability.
- Thermal management: 20mm ventilation gap ensures passive cooling airflow.
- Anti-theft security: Tamper-proof bolts and key-lock option available.
Technical Details
- Load capacity: 120kg (2x battery stack + inverter).
- Material: 6063-T6 aluminium alloy (3.2mm wall thickness).
- Surface treatment: Electrophoretic coating + UV powder coat.
- Fixing points: 8x M10 wall anchors (concrete/brick) or 4x M8 studs (timber).
- Vibration resistance: 10G acceleration (IEC 60068-2-6 compliant).
- Corrosion resistance: Salt spray tested 1000hrs (ASTM B117).
- Compatibility: Power Ocean battery (680x183x452mm), inverter wall-mount versions.
Physical Specifications
- Bracket dimensions (W × D × H): 720 × 200 × 500mm (battery single).
- Stacked configuration: 720 × 200 × 1050mm (2x batteries).
- Weight: 4.8kg (single bracket).
- Wall protrusion: 200mm from wall face.
- Clearance below: 150mm for cable routing and ventilation.
- Finish: Textured matt black (RAL 9005).
System & Application Notes
- Installation: Requires solid wall (concrete/brick minimum 100mm thick) or reinforced timber studs; professional fixing recommended.
- Configurations: Single battery wall-mount, dual battery stack, inverter + battery combo.
- Alternatives: Floor-standing base also available for garages/utility rooms.
- Maintenance: Zero maintenance; 10-year corrosion warranty.
- Certifications: CE marked, EN1090 structural steel, MCS compliant.
- Applications: Space-constrained installations, aesthetic garage walls, outdoor utility areas.
Original: $255.09
-65%$255.09
$89.28More Images
