Ideal Heating Logic Air Monobloc Air Source Heat Pumps | 4-10kW R32 Range

The Ideal Logic Air monobloc range delivers SCOP up to 5.19 efficiency using low GWP R32 refrigerant across 4kW to 10kW capacities. These single-phase units provide quiet, radiator-compatible heating with smart weather compensation and solar PV readiness. Quiet Mark certified operation ensures residential suitability with 5-year warranty backing.

Available Variants

Model	Part No	Capacity	COP A7/W35	Dimensions (W x H x D)	Weight
Logic Air 4kW	AH750664	4.0 kW	5.34	798 x 1095 x 521 mm	86 kg
Logic Air 5kW	AH750665	5.0 kW	5.19	798 x 1095 x 521 mm	86 kg
Logic Air 8kW	AH750666	8.2 kW	5.0	518 x 1008 x 1095 mm	110 kg
Logic Air 10kW	AH750667	10.3 kW	4.9	518 x 1008 x 1095 mm	110 kg

Why Buy Ideal Logic Air Heat Pumps?

• SCOP up to 5.19 efficiency (A+++ @ 35°C) minimises running costs
• Low GWP R32 refrigerant with zero ozone depletion potential
• Quiet Mark certified operation (52-55 dB(A)) for residential use
• Monobloc design - no F-Gas qualification required
• Radiator and underfloor heating compatible with smart weather compensation
• Solar PV and smart grid ready for hybrid renewable systems
• 5-year warranty with UK-based support 364 days/year
• Fast hot water reheat with Ideal Heat Pump Cylinder range

Suitable For

• New build homes requiring efficient monobloc ASHP solutions
• Existing properties with radiator systems (low-temp optimised)
• Small to medium homes matching 4-10kW heating demands
• Solar PV owners seeking integrated renewable heating
• Properties prioritising quiet operation and simple installation

Common Technical Specifications

Specification	Details
Refrigerant	R32 (Low GWP)
Power Supply	230V Single Phase
Max Flow Temperature	60°C
Operating Range (Air)	-20°C to +35°C
Energy Rating	A+++ (35°C) / A++ (55°C)
Connections	28mm flow/return
Control	Halo Air thermostat compatible
Warranty	5 Years (extendable)
