Easee 100A Three Phase Equalizer

The Easee 100A Three Phase Equalizer is an intelligent load balancing device designed to optimize electric vehicle charging by dynamically balancing the total energy consumption between the Easee Charging Robots and the electrical load of your building. Suitable for homes, apartment blocks, offices, and commercial buildings, it enhances charging speed and safety while minimizing infrastructure upgrade costs.

Key Features

• Dynamic load balancing on three-phase systems up to 100 amps
• Continuously monitors power consumption and adjusts charging power accordingly
• Supports up to 6 Easee Charging Robots simultaneously
• Integrates with Easee Link RF and WiFi for smart communication and control
• Compact design with magnetic back for easy mounting on metal surfaces or included wall plate
• Compatible with Modbus meters, preferably Eastron SDM series
• Three-year manufacturer warranty

Technical Specifications

Model	Easee Equalizer 100A - Three Phase
Part Code	90501UK
EAN	7090052312872
Dimensions	110mm x 110mm x 27.5mm (H x W x D)
Weight	Approx. 95g
Ingress Protection	IP40
Operating Temperature	-20°C to 50°C
Power Supply	5–30 V DC, 100 mA
Connectivity	WiFi, Easee Link RF, Modbus
Load Balancing	Dynamic via Modbus meter interface
Warranty	3 years

Applications

• Efficient energy management for buildings with electric vehicle charging stations
• Reducing overload risks while maximizing charging power
• Integration in residential, commercial, and multi-dwelling unit installations

Why Choose the Easee 100A Three Phase Equalizer?

• Enables faster EV charging without costly electrical infrastructure upgrades
• Smart communication ensures seamless coordination with Easee Charging Robots
• Small footprint and easy installation for installers
